VM Energy Solutions INC is a famous supplier and manufacturer of CS Seamless Pipes, which areavailable in best reasonable rates Compared to chromium-nickel austenitic steels, Carbon Steel Seamless Pipes gives better creep, strain to rupture and tensile strength at improved temperatures. Although the forming functionality may be very just like different grades, temperature version for this steel may have much less had an effect on material conduct. However, its proven ability to fight corrosion has widened its use notably and so it & s miles now getting used for plenty different industrial applications. Low speeds and steadyfeeds will decrease this tendency of this alloy to working harden. Lower carbon content material onthis steel ends in resistance to sensitization while welded.
Carbon Steel Seamless Pipes machines as do different austenitic steels, to provide tough, stringy chips, in which sluggish speeds, heavy feeds and sharp tooling will serve to enhance machinability. For this purpose a low heat enter and a maximum inter-pass temperature of one hundred Degree C on this alloy ought to be used. Shearing, stamping, heading and drawing are viable with this product, and post-paintings annealing is suggested to get rid of inner stresses. The conduct of this steel can also additionally alternate because of situations of temperature, pH, contaminants, and additionally the conservation of gear utilized in welding and conformation.
Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
---|---|
Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
Size Range | Cold rolled Plate 0.5-6.4 mm Hot rolled Plate 3.0–10.0 mm |
Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
Thickness | 0.3 mm to 120 mm |
International Standard | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
Tolerances (width / thickness) | EN 10258/ DIN 59381) EN 10151 EN 10088 |
Finish | 2B, 2D, BA NO (8), Cold rolled Plate (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
Plate Surface finish | Thickness (mm) | Width (max mm) |
---|---|---|
2B – Cold rolled, heat treated, pickled, skin passed Sheet | 0.25–8.0 | 2032 |
2D – Cold rolled, heat treated, pickled Sheet | 0.4–6.35 | 1524 |
2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
2H – Work hardened plate | 0.4–6.35 | 1524 |
Polished, brushed plate | 0.5–4.0 | 1524 |
Plate Surface finish | Gauge (in) | Width (max in) |
2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
BA Mexinox only | 18–28 | 48 |
Polished Sheet (not brushed) | 11–24 | 60 |
Temper rolled Sheet Mexinox only | 13–29 | 48 |
STANDARD | WERKSTOFF NR. | UNS | JIS | EN | BS | AFNOR | GOST |
SS 430 | 1.4016 | S43000 | SUS 430 | X6Cr17 | 430S17 / 430S18 | Z8C17 | 12KH17 |
Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
---|---|---|---|---|---|---|
inches | mm | lbs/ft² | kg/m² | lbs | kg | |
0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Plate Thickness (mm) | Weight (kg/m) | kg/meter (width 1200mm) | kg/meter (width 1500mm) | kg/meter (width 1800mm) | kg/meter (width 2400mm) |
3 | 23.55 | 28.3 | 35.3 | 42.4 | 56.5 |
4 | 31.4 | 37.7 | 47.1 | 56.5 | 75.4 |
5 | 39.25 | 47.1 | 58.9 | 70.7 | 94.2 |
6 | 47.1 | 56.5 | 70.7 | 84.8 | 113 |
8 | 62.8 | 75.4 | 94.2 | 113 | 150.7 |
10 | 78.5 | 94 | 118 | 141 | 188 |
12 | 94.2 | 113 | 141 | 170 | 226 |
16 | 125.6 | 151 | 188 | 226 | 301 |
20 | 157 | 188 | 236 | 283 | 377 |
22 | 172.7 | 207 | 259 | 311 | 415 |
25 | 196.25 | 236 | 294 | 353 | 471 |
28 | 219.8 | 264 | 330 | 396 | 528 |
32 | 251.2 | 301 | 377 | 452 | 603 |
36 | 282.6 | 339 | 424 | 509 | 678 |
40 | 314 | 377 | 471 | 565 | 754 |
45 | 353.25 | 424 | 530 | 636 | 848 |
50 | 392.5 | 471 | 589 | 707 | 942 |
55 | 431.75 | 518 | 648 | 777 | 1036 |
60 | 471 | 565 | 707 | 848 | 1130 |
65 | 510 | 612 | 765 | 918 | 1224 |
70 | 549.5 | 659 | 824 | 989 | 1319 |
75 | 588.75 | 707 | 883 | 1060 | 1413 |
80 | 628 | 754 | 942 | 1130 | 1507 |
90 | 706.5 | 848 | 1060 | 1272 | 1696 |
100 | 785 | 942 | 1178 | 1413 | 1884 |
EU EN |
USA - |
Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Italy UNI |
China GB |
Sweden SS |
Poland PN |
Czechia CSN |
Russia GOST |
X6Cr17 (1.4016) | 430 S43000 |
X6Cr17 | SUS430 | Z8C17 | 430S17 430S18 |
X8Cr17 | 1Cr15 | 2320 | H17 | 17040 | 12KH17 |
Grade | %C | %Mn | %P | %S | %Si | %Cr | %Ni |
SS 430 | 0.120 | 1.000 | 0.040 | 0.030 | 1.00 | 16.00-18.00 | 0.75 max |
Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX |
430 | 552 | 379 | 25 | 262 |
We Manufacturer, Supplier and Exporter ASTM A240 Stainless Steel 430 Plates for wide range of industries. Some of the examples are : – Constructions, Sugar Mills, Shipbuilding, Refineries, Petrochemicals, Railways, Automobiles, Pharmaceuticals, Chemicals, Architectural applications, Power Plants, Paper & Pulp Industries, Water Pipelines, Dairies & Breweries, Food & Beverages, Textiles, Nuclear etc.
