An established distributor of Monel 400 Coils, Nandini Steel has the superior quality to fully satisfy all of the needs of its clients. The alloy has excellent resistance to oxidising chemical compounds and high-temperature oxidising gases thanks to its high chromium concentration. Nitric acid applications or nitric acid with hydrochloric acid applications are connected to Monel Alloy UNS N04400 Coils. Examples include steam-heating coils in nitric-plus-hydrochloric acid solutions used for pickling steel and reprocessing nuclear fuels and tail-fueloline re-heaters used in the production of nitric acid. The alloy has excellent resistance to oxidising chemical compounds and high-temperature oxidising gases thanks to its high chromium concentration. For strengthening the great alloys, work hardening, precipitation hardening, and solid-solution hardening are completed.
It exhibits low corrosion rates and exceptional resistance to stress-corrosion cracking in several types of high-temperature water. In gases containing sulphur, Monel WNR 2.4361 Coils are also useful as an excessive temperature supplier. Metal alloy mechanical properties in relation to product shape and temper. Burners with high temperatures, ductwork, furnaces, and warmers for petrochemicals. Exceptional resistance to stress-corrosion cracking is seen. It is possible to employ traditional machining techniques for alloys that are predominantly based on iron. It does work-harden during machining, has greater strength, and is no longer regarded as a typical steel. This grade's applications are primarily found in the chemical industries. It was demonstrated that polythionic acid did not break when exposed to a solution that cracked sensitive steel.
Standard | JIS, ASTM, AISI, GB, EN, DIN |
Size | 1000mm, 1219mm, 1250mm, 1500mm, 1524mm, 2000mm, etc |
Thickness | 0.3mm--100mm |
Surface | No.8 Finish, 2B Finish, No.1 Finish, No.4 Finish, Brushed Finish, BA Finish, 8K Finish, Embossed Finish, etc |
Finish | Cold Rolled Coil (CR), 2B, BA, Hot Rolled Coil (HR), No.8 |
Brand | Indian Origin, Korea Origin, European Origin, Taiwan Origin, US Origin, Japanese Origin, Thailand Origin |
Manufacturer | Arcelor Mittal, TISCO, Baosteel, POSCO, Outokumpu, Aperam, Jindal Stainless, VDM, Nippon Metal, Thyssenkrup, DKC Korea |
Package | Standard export package, suit for all kinds of transport, or as required. |
Brushed Finish Coil | No.1 Finish Coils |
Embossed Finish Coil | 2B Matte Finish Coils |
No.8 Finish Coils | Bright Annealed Finish Coil |
No.4 Finish Coil | BA Finish Coil |
No.3 Finish Coil | HL Finish Coil |
STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
Monel 400 | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Size (millimeter) |
Wght per Coil (kilogram) |
Size (millimeter) |
Wght per Coil (kilogram) |
---|---|---|---|
2000 x 1000 x 3.0 | 51.0 | 4000 x 2000 x 6.0 | 408.0 |
2500 x 1250 x 3.0 | 79.7 | 2500 x 1250 x 8.0 | 213.0 |
3000 x 1500 x 3.0 | 115.0 | 3000 x 1500 x 8.0 | 306.0 |
2000 x 1000 x 4.0 | 68.0 | 4000 x 2000 x 8.0 | 544.0 |
2500 x 1250 x 4.0 | 106.0 | 2500 x 1250 x 10.0 | 266.0 |
3000 x 1500 x 4.0 | 153.0 | 3000 x 1500 x 10.0 | 383.0 |
2000 x 1000 x 5.0 | 85.0 | 4000 x 1500 x 10.0 | 510.0 |
2500 x 1250 x 5.0 | 133.0 | 4000 x 2000 x 10.0 | 680.0 |
3000 x 1500 x 5.0 | 191.0 | 2500 x 1250 x 12.0 | 319.0 |
4000 x 2000 x 5.0 | 340.0 | 3000 x 1500 x 12.0 | 459.0 |
2000 x 1000 x 6.0 | 102.0 | 4000 x 1500 x 12.0 | 612.0 |
2500 x 1250 x 6.0 | 159.0 | 4000 x 2000 x 12.0 | 816.0 |
3000 x 1500 x 6.0 | 230.0 |
Size (millimeter) | Wght per Coil (Kilogram) |
Size(millimeter) | Wght per Coil (Kilogram) |
---|---|---|---|
4000 x 2000 x 2.0 | 136.0 | 3000 x 1500 x 5.0 | 191.0 |
4000 x 2000 x 3.0 | 204.0 | 4000 x 2000 x 5.0 | 340.0 |
2500 x 1250 x 4.0 | 106.0 | 2500 x 1250 x 6.0 | 159.0 |
3000 x 1500 x 4.0 | 153.0 | 3000 x 1500 x 6.0 | 230.0 |
4000 x 2000 x 4.0 | 272.0 | 4000 x 2000 x 6.0 | 408.0 |
2500 x 1250 x 5.0 | 133.0 |
Strip Thickness | Width | |||
---|---|---|---|---|
320≤W<600 | W<320 | |||
T1 | T2 | T3 | T4 | |
T<0.05 mm | 0.004 | 0.003 | 0.003 | 0.002 |
0.05≤T<0.07 | 0.005 | 0.004 | 0.004 | 0.003 |
0.07≤T<0.08 | 0.006 | 0.005 | 0.005 | 0.003 |
0.08≤T<0.10 | 0.007 | 0.005 | 0.005 | 0.003 |
0.10≤T<0.13 | 0.009 | 0.007 | 0.006 | 0.004 |
0.13≤T<0.15 | 0.010 | 0.008 | 0.007 | 0.004 |
0.15≤T<0.20 | 0.011 | 0.009 | 0.008 | 0.004 |
0.20≤T<0.25 | 0.013 | 0.010 | 0.008 | 0.005 |
0.25≤T<0.30 | 0.015 | 0.011 | 0.009 | 0.005 |
0.30≤T<0.35 | 0.016 | 0.012 | 0.010 | 0.005 |
0.35≤T<0.40 | 0.018 | 0.012 | 0.010 | 0.005 |
0.40≤T<0.50 | 0.020 | 0.015 | 0.012 | 0.005 |
0.50≤T<0.60 | 0.022 | 0.018 | 0.013 | 0.005 |
0.60≤T<0.70 | 0.024 | 0.020 | 0.015 | 0.005 |
0.70≤T<0.80 | 0.026 | 0.022 | 0.017 | 0.005 |
0.80≤T<0.90 | 0.028 | 0.024 | 0.018 | 0.006 |
0.90≤T<1.00 | 0.032 | 0.027 | 0.020 | 0.008 |
1.00≤T<1.20 | 0.035 | 0.030 | 0.022 | 0.008 |
1.20≤T<1.40 | 0.040 | 0.035 | 0.025 | 0.010 |
1.40≤T<1.60 | 0.045 | 0.040 | 0.030 | 0.020 |
Thick. on base (millimeter) | Unit Wght / Coil (kilogram) |
---|---|
3000 x1000 x3.0 | 78.0 |
3000 x1250 x4.5 | 143.0 |
3000 x1250 x6.0 | 180.0 |
3000 x1250 x8.0 | 210.0 |
EU EN |
USA - |
Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Italy UNI |
China GB |
Sweden SS |
Poland PN |
Czechia CSN |
Finland SFS |
Austria ONORM |
Russia GOST |
DIN 17750 2.4360 |
400 UNS N04400 |
2.4360 | NW 4400 | NU-30M | NA 13 BS 3072NA1 BS 3076NA13 |
- | - | - | - | - | - | - | МНЖМц 28-2,5-1,5 |
Grade | Ni | C | Al | Mn | Si | Fe | Cu | S |
Monel 400 | 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 - 2.5 | 28.0 - 34.0 | 0.02 max |
Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
We Manufacturer, Supplier and Exporter ASTM B127 Monel 400 Coils for wide range of industries. Some of the examples are : – Petrochemicals, Architectural applications, Refineries, Shipbuilding, Textiles, Nuclear, Sugar Mills, Dairies & Breweries, Paper & Pulp Industries, Automobiles, Railways, Pharmaceuticals, Food & Beverages, Chemicals, Constructions, Water Pipelines, Power Plants etc.
