Nickel Alloy 201 Pipes & Tubes Stockist in India

  • Home
  • Pipes & Tubes

Nickel Alloy 201 ERW Pipes, Alloy 201 Tubing Price, Nickel 201 Seamless Pipe, UNS N02201 Pipes Stockists in Mumbai, India.

Table of Contents

What is Nickel Alloy 201 Pipes & Tubes ?
Nickel Alloy 201 Pipes & Tubes Specification
Different Nickel Alloy 201 Pipes & Tubes Types
Nickel Alloy 201 Pipes & Tubes Equivalent Material Grade
Nickel Alloy 201 Pipe Size Chart
Nickel Alloy 201 Tubing Dimensions
Chemical Composition of Nickel Alloy 201 Pipes & Tubes
Mechanical Properties of Nickel Alloy 201 Pipes & Tubes
Nickel Alloy 201 Pipes & Tubes Sizes in Stock
Available Stock of Nickel Alloy 201 Pipes & Tubes
Industries & Applications

A well-known supplier and seller of Nickel Alloy 201 Pipes & Tubes, an unstabilized low carbon excessive alloy austenitic material, is Nandini Steel. At temperatures above 800 degrees Celsius, the titanium atoms stabilise the form of, preventing carbide from precipitating on the grain barriers and shielding the steel from corrosion. An air jet directed at the device may also significantly boost device existence at any factor where dry slicing is recommended. It may also work just as well to use water-based cooling spray. Despite its propensity to work-harden, it can be efficiently spun, deep-drawn, press-formed, or punched. These Nickel Alloy UNS N02201 Instrumentation Tubes' reduced carbon footprint in terms of thermal expansion

Due to its exceptional strength, Nickel Alloy WNR 2.4068 High Pressure Pipes can become unstable at temperatures between 1020 and 1080 degrees Celsius. This makes bending and shaping more difficult. Larger potential devices would be needed for these activities than would be necessary for austenitic form. Its ductility is significantly lower than that of an austenitic grade (though it isn't necessarily low when compared to the majority of other structural materials), making excessive shaping procedures like cold heading typically impractical. It is strongly advised to do interim annealing if extreme cold working is required.

Nickel Alloy 201 Pipes & Tubes

Nickel Alloy 201 Seamless Tubes, ASTM B730 Nickel 201 ERW Tubing, DIN 2.4068 Pipes Supplier in Mumbai, India.

It cannot always be used at temperatures above 300 degrees Celsius because it does not suffer from the precipitation of brittle micro-components, nor can it be used below -50 degrees Celsius because of its ductile-to-brittle transition. Low carbon content materials reduce the amount of grain-boundary carbide that forms during welding, maintaining corrosion resistance in the warm-affected areas of welded joints. It now has significantly improved resistance to powerful reducing acids, especially sulphuric acid, because to the inclusion of copper. Nickel Alloy 201 Seamless Tubes are notably known for being strong, well-made, long-lasting, and dependable.
Pipes & Tubes
Alloy 201, UNS N02201, 2.4068, EN LC-Ni 99, JIS NW 2201, BS NA 12, GOST НП-2, DIN 17750, BS 3072-3076 PIPES & TUBES STOCKIST.

Nickel Alloy 201 Pipes & Tubes Specification

Standards
  • ASTM B161 / ASME SB161
  • ASTM B163 / ASME SB163
  • ASTM B725 / ASME SB725
  • ASTM B730 / ASME SB730
Specialized in Large Diameter Pipe
Pipe size 4 to 219 Milimeter W. T.: 0.5 to 20 Milimeter
Tube Size 1 mm OD upto 254 mm OD in 0.2 TO 20 mm thickness.
Sizes in Inch 15 Inch NB TO 150 Inch NB IN
Schedule SCH5, SCH40, SCH10, STD, SCH160, SCH80
Length Double, Single Random & Cut Length.
Form Hydraulic, Round Etc
End Plain End, Treaded, Beveled End
Material Test Certificates (MTC) EN 10204 3.1
EN 10204 3.2
Marking All Pipes are marked as follows: Grade, Standard, Thickness, OD, Heat No. (Or according to the customer’s request.), Length
Finish Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF
Wall Thickness 0.020" to 0.220", (special wall thicknesses available)

Different Nickel Alloy 201 Pipes & Tubes Types

Nickel Alloy 201 Seamless Pipe
Nickel Alloy 201 Seamless Pipe
Nickel Alloy 201 Welded Pipe
Nickel Alloy 201 Welded Pipe
Nickel Alloy 201 ERW Pipe
Nickel Alloy 201 ERW Pipe
Nickel Alloy 201 EFW Pipe
Nickel Alloy 201 EFW Pipe
Nickel Alloy 201 Seamless Tubes
Nickel Alloy 201 Seamless Tubes
Nickel Alloy 201 Welded Tubes
Nickel Alloy 201 Welded Tubes

Nickel Alloy 201 Pipes & Tubes Equivalent Material Grade

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Nickel 201 2.4068 N02201 NW 2201 NA 12 НП-2 - LC-Ni 99

Nickel Alloy 201 Pipe Size Chart

PIPE SIZE OD IN INCHES A.S.A. Pipe Schedules
5s 5 10s 10 20 30 40s & Std. 40 60 80s & E.H. 80 100 120 140 160 DBL E.H.
1/8 .405 .035.1383 .049.1863 .049.1863 .068.2447 068.2447 0.95.3145 0.95.3145
1/4 .540 .049.2570 .065.3297 .065.3297 .088.4248 088.4248 .119.5351 .119.5351
3/8 .675 .049.3276 .065.4235 .065.4235 .091.5676 .091.5676 .126.7338 .126.7338
1/2 .840 .065.5383 .065.5383 .083.6710 .083.6710 .109.8510 .109.8510 .1471.088 .1471.088 .1871.304 .2941.714
3/4 1.050 .065.6838 .065.6838 .083.8572 .083.8572 .1131.131 .1131.131 .1541.474 .1541.474 .2181.937 .3082.441
1 1.315 .065.8678 .065.8678 .1091.404 .1091.404 .1331.679 .1331.679 .1792.172 .1792.172 .2502.844 .3583.659
1-1/4 1.660 .0651.107 .0651.107 .1091.806 .1091.806 .1402.273 .1402.273 .1912.997 .1912.997 .2503.765 .3825.214
1-1/2 1.900 .0651.274 .0651.274 .1092.085 .1092.085 .1452.718 .1452.718 .2003.631 .2003.631 .2814.859 .4006.408
2 2.375 .0651.604 .0651.604 .1092.638 .1092.638 .1543.653 .1543.653 .2185.022 .2185.022 .3437.444 .4369.029
2-1/2 2.875 .0832.475 .0832.475 .1203.531 .1203.531 .2035.793 .2035.793 .2767.661 .2767.661 .37510.01 .55213.70
3 3.500 .0833.029 .0833.029 .1204.332 .1204.332 .2167.576 .2167.576 .30010.25 .30010.25 .43714.32 .60018.58
3-1/2 4.000 .0833.472 .0833.472 .1204.973 .1204.973 .2269.109 .2269.109 .31812.51 .31812.51 .63622.85
4 4.500 .0833.915 .0833.915 .1205.613 .1205.613 .23710.79 .23710.79 .28112.66 .33714.98 .33714.98 .43719.01 .53122.51 .67427.54
4-1/2 5.000 .24712.53 .35517.61 .71032.53
5 5.563 .1096.349 .1096.349 .1347.770 .1347.770 .25814.62 .25814.62 .37520.78 .37520.78 .50027.04 .62532.96 .75038.55
6 6.625 .1097.585 .1097.585 .1349.290 .1349.290 .28018.97 .28018.97 .43228.57 .43228.57 .56236.39 .71845.30 .86453.16
7 7.625 .30123.57 .50038.05 .87563.08

Nickel Alloy 201 Tubing Dimensions

Size
OD, Inches		 BW
Ga.		 Wall
Dec-In.		 ID Weight
Lbs/Ft.
1/8 22 0.028 0.069 0.0290
20 0.035 0.055 0.0336
3/16 22 0.028 0.131 0.0478
1/4 25 0.020 0.210 0.0491
22 0.028 0.194 0.0664
21 0.032 0.187 0.0745
20 0.035 0.180 0.0804
18 0.049 0.152 0.1052
16 0.065 0.120 0.1284
5/16 20 0.035 0.242 0.1039
18 0.049 0.214 0.1382
16 0.065 0.182 0.1722
3/8 22 0.028 0.319 0.1038
20 0.035 0.305 0.1271
18 0.049 0.277 0.1706
16 0.065 0.245 0.2152
7/16 18 0.049 0.340 0.2036
1/2 25 0.020 0.460 0.1025
20 0.035 0.430 0.1738
18 0.049 0.402 0.2360
16 0.065 0.370 0.3020
5/8 20 0.035 0.555 0.2205
18 0.049 0.527 0.3014
16 0.065 0.495 0.3888
3/4 20 0.035 0.680 0.2673
18 0.049 0.652 0.3668
16 0.065 0.620 0.4755
14 0.083 0.584 0.5913
7/8 18 0.049 0.777 0.4323
16 0.065 0.745 0.5623
11 0.120 0.635 0.9676
1 20 0.035 0.930 0.3607
18 0.049 0.902 0.4977
16 0.065 0.870 0.6491
14 0.083 0.834 0.8129
11 0.120 0.760 1.1278
1-1/4 11 0.120 1.010 1.4480
OD inches Ave. Wall inches D/t Ratio ID inches Tubing Cross Sectional Area (in2) Internal Area (in2)
0.250 0.020 12.50 0.210 0.0145 0.0346
0.250 0.028 8.93 0.194 0.0195 0.0296
0.250 0.035 7.14 0.180 0.0236 0.0254
0.250 0.049 5.10 0.152 0.0309 0.0181
0.250 0.065 3.85 0.120 0.0378 0.0113
0.375 0.020 18.75 0.335 0.0223 0.0881
0.375 0.028 13.39 0.319 0.0305 0.0799
0.375 0.035 10.71 0.305 0.0374 0.0731
0.375 0.049 7.65 0.277 0.0502 0.0603
0.375 0.065 5.77 0.245 0.0633 0.0471
0.500 0.020 25.00 0.460 0.0302 0.1662
0.500 0.028 17.86 0.444 0.0415 0.1548
0.500 0.035 14.29 0.430 0.0511 0.1452
0.500 0.049 10.20 0.402 0.0694 0.1213
0.500 0.065 7.69 0.370 0.0888 0.1075
0.500 0.083 6.02 0.334 0.1087 0.0876
0.625 0.020 31.25 0.585 0.0380 0.2688
0.625 0.028 22.32 0.569 0.0525 0.2543
0.625 0.035 17.86 0.555 0.0649 0.2419
0.625 0.049 12.76 0.527 0.0887 0.2181
0.625 0.065 9.62 0.495 0.1144 0.1924
0.625 0.083 7.53 0.459 0.1413 0.1655
0.625 0.095 6.58 0.435 0.1582 0.1486
0.625 0.109 5.73 0.407 0.1767 0.1301
0.750 0.028 26.79 0.694 0.0635 0.3783
0.750 0.035 21.43 0.680 0.0786 0.3632
0.750 0.049 15.31 0.652 0.1079 0.3339
0.750 0.065 11.54 0.620 0.1399 0.3019
0.750 0.083 9.04 0.584 0.1739 0.2679
0.750 0.095 7.89 0.560 0.1955 0.2463
0.750 0.109 6.88 0.532 0.2195 0.2223
0.750 0.120 6.25 0.510 0.2375 0.2043
0.875 0.020 43.75 0.835 0.0537 0.5476
0.875 0.028 31.25 0.819 0.0745 0.5268
0.875 0.035 25.00 0.805 0.0924 0.5090
0.875 0.049 17.86 0.777 0.1272 0.4742
0.875 0.065 13.46 0.745 0.1654 0.4359
0.875 0.083 10.54 0.709 0.2065 0.3948
0.875 0.095 9.21 0.685 0.2328 0.3685
0.875 0.109 8.03 0.657 0.2623 0.3390
0.875 0.120 7.29 0.635 0.2846 0.3167
1.000 0.028 35.71 0.944 0.0855 0.6999
1.000 0.035 28.57 0.930 0.1061 0.6793
1.000 0.049 20.41 0.902 0.1464 0.6390
1.000 0.065 15.38 0.870 0.1909 0.5945
1.000 0.083 12.05 0.834 0.2391 0.5463
1.000 0.095 10.53 0.810 0.2701 0.5153
1.000 0.109 9.17 0.782 0.3051 0.4803
1.000 0.120 8.33 0.760 0.3318 0.4536
1.000 0.134 7.46 0.732 0.3646 0.4208
1.250 0.035 35.71 1.180 0.1336 1.0936
1.250 0.049 25.51 1.152 0.1849 1.0423
1.250 0.065 19.23 1.120 0.2420 0.9852
1.250 0.083 15.06 1.084 0.3043 0.9229
1.250 0.095 13.16 1.060 0.3447 0.8825
1.250 0.109 11.47 1.032 0.3907 0.8365
1.250 0.120 10.42 1.010 0.4260 0.8012
1.250 0.134 9.33 0.982 0.4698 0.7574
1.500 0.035 42.86 1.430 0.1611 1.6061
1.500 0.049 30.61 1.402 0.2234 1.5438
1.500 0.065 23.08 1.370 0.2930 1.4741
1.500 0.083 18.07 1.334 0.3695 1.3977
1.500 0.095 15.79 1.310 0.4193 1.3478
1.500 0.109 13.76 1.282 0.4763 1.2908
1.500 0.120 12.50 1.260 0.5202 1.2469
1.500 0.134 11.19 1.232 0.5750 1.1921
1.500 0.148 10.14 1.204 0.6286 1.1385
1.750 0.035 50.00 1.680 0.1886 2.2167
1.750 0.049 40.82 1.902 0.3003 2.8413
1.750 0.065 26.92 1.620 0.3441 2.0612
1.750 0.083 21.08 1.584 0.4347 1.9706
1.750 0.095 18.42 1.560 0.4939 1.9113
1.750 0.109 16.06 1.532 0.5619 1.8433
1.750 0.120 14.58 1.510 0.6145 1.7908
1.750 0.134 13.06 1.482 0.6803 1.7250
1.750 0.148 11.82 1.454 0.7449 1.6604
1.750 0.165 10.61 1.420 0.8216 1.5837
2.000 0.035 57.14 1.930 0.2161 2.9255
2.000 0.049 40.82 1.902 0.3003 2.8413
2.000 0.065 30.77 1.870 0.3951 2.7465
2.000 0.083 24.10 1.834 0.4999 2.6417
2.000 0.095 21.05 1.810 0.5685 2.5730
2.000 0.109 18.35 1.782 0.6475 2.4941
2.000 0.120 16.67 1.760 0.7087 2.4328
2.000 0.134 14.93 1.732 0.7855 2.3561
2.000 0.148 13.51 1.704 0.8611 2.2805
2.000 0.165 12.12 1.670 0.9512 2.1904
Pipes & Tubes
Contact Nandini Steel for you all requirement of Nickel Alloy 201 Pipes & Tubes in South Africa, Russia, South Korea, USA, Malaysia, Saudi Arabia, Bahrain, Kuwait, Morocco, UAE.
Stockist of Alloy 201 Seamless Pipes in India, Nickel 201 Seamless Tubing in various sizes.
ENQUIRY NOW

Worldwide equivalents of grade 201

EU
EN 		USA
-		 Germany
DIN,WNr		 Japan
JIS 		France
AFNOR		 England
BS		 Italy
UNI		 China
GB		 Sweden
SS		 Poland
PN		 Czechia
CSN		 Finland
SFS		 Austria
ONORM		 Russia
GOST
LC-Ni 99 201
UNS N02201		 2.4068 NW 2201 - NA 12
BS 3072-3076		 - - - - - - - НП-2

Chemical Composition of Nickel Alloy 201 Pipes & Tubes

Grade C Mn Si S Cu Fe Ni
Nickel 201 0.2 max 0.35 max 0.35 max 0.01 max 0.25 max 0.40 max 99.0 min

Mechanical Properties of Nickel Alloy 201 Pipes & Tubes

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Nickel 201 8.9 g/cm3 1446 °C (2635 °F) Psi – 67000 , MPa – 462 Psi – 21500 , MPa – 148 45 %

You May Also Like Buy These Grades :


We offer These Alloy 201 Pipes & Tubes as per ASTM, ASME, BS, DIN, EN.
REQUEST A QUOTE

Available Stock of Nickel Alloy 201 Pipes & Tubes

  • Alloy 201 Seamless Pipes Stockist
  • Nickel Alloy BS 3072-3076 Tubes
  • EN LC-Ni 99 SMLS Pipe
  • Nickel 201 Cold Drawn Pipe
  • Nickel Alloy 201 Heat Exchanger Tubes
  • JIS NW 2201 Piping
  • DIN 2.4068 Tubes Suppliers in India
  • Nickel Alloy 201 Pipe Supplier
  • 201 Nickel Schedule 40 Seamless Pipe
  • Alloy 201 Cold Drawn Seamless Tube
  • ASTM B161 Alloy 201 EFW Pipe Price Per KG
  • GOST НП-2 Pipe

Industries & Applications Where Our Nickel Alloy 201 Pipes & Tubes is Used

We Manufacturer, Supplier and Exporter ASTM B161 Nickel Alloy 201 Pipes & Tubes for wide range of industries. Some of the examples are : – Water Pipelines, Chemicals, Nuclear, Sugar Mills, Architectural applications, Pharmaceuticals, Paper & Pulp Industries, Refineries, Constructions, Dairies & Breweries, Food & Beverages, Textiles, Railways, Power Plants, Petrochemicals, Shipbuilding, Automobiles etc.

Oil & Gas
0%
Chemicals
0%
Shipbuilding
0%
Power Plants
0%
Paper & Pulp Industries
0%
Railways
0%
