ASTM SA387 Gr 12 Sheets Stockist in India
ASTM A387 CrMo Gr 12 Sheet, Chromium-Molybdenum Gr 12 Sheet, Alloy Steel Gr 12 Sheet, UNS K11757 Sheets Stockists in Mumbai, India.
Table of Contents
As a reputable stockist of Alloy Steel ASTM SA387 Grade 12 Sheets, Nandini Steel is well-known for its products' first-rate quality, superior performance, rust-free nature, and durability. Because of its increased resistance to chloride corrosion, it is frequently referred to as amazing metallic and is an ideal material for usage in salt water situations. These manufactured sheets are well-known and goal-oriented due to their close tolerance and dimensional correctness. As a reputable business, we deal in buying, selling, and displaying a wide range of ASME SA 387 Alloy Steel Grade 12 Sheets. These sheets find use in heavy-duty industrial applications and may be made to order in a number of sizes. We have really favourable reviews in handling.
It is prized for its enhanced weldability, resistance to corrosion and abrasion, resistance to pressure cracking, and other qualities. It may be obtained by using our employer, which was meticulously manufactured with the use of cutting-edge machinery. With the help of our team of engineers and other talented and unskilled workers, we offer a huge range of different types of synthetic Alloy Steel ASTM SA387 Grade 12 Perforated Sheets with common first-class and high performance. It is frequently praised for its supreme quality, durability, affordability, availability in a variety of sizes, high standards of quality sacrifice, dependable raw materials, elegant design, and other qualities.
Alloy Steel Grade 12 Sheet Price, ASME SA387 Gr 12 Chrome Moly Sheet, CrMo Grade 12 Cold Rolled Sheet Supplier in Mumbai, India.
| Specifications | ASTM A387 / ASME SA387 |
|---|---|
| Dimension Standard | AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold rolled Sheet 0.5-6.4 mm Hot rolled Sheet 3.0–10.0 mm |
| Width | 1000mm-4500mm |
| Length | 3000mm -18000mm |
| Thickness | 5mm-150mm |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | AFNOR | GOST | EN |
| Alloy Steel Gr 12 | 1.7335 | K11757 | SFVAF12 | 620 | 15CD2.05 15CD4-05 15CD4-5 |
12KHM 15KHM |
13CrMo4-5 |
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
|---|---|---|---|---|---|---|
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
| THICKNESS IN MM | SIZE IN MM | WEIGHT KG/M2 | ||
| 2000 X 1000 | 2500 X 1250 | 3000 X 1500 | ||
| 0.18 | 2.88 | - | - | 1.44 |
| 0.20 | 3.20 | - | - | 1.60 |
| 0.22 | 3.52 | - | - | 1.76 |
| 0.24 | 3.84 | - | - | 1.92 |
| 0.27 | 4.32 | - | - | 2.16 |
| 0.28 | 4.48 | - | - | 2.24 |
| 0.32 | 5.12 | - | - | 2.56 |
| 0.38 | 6.08 | - | - | 3.04 |
| 0.44 | 7.04 | 11.00 | - | 3.52 |
| 0.50 | 8.00 | 12.50 | - | 4.00 |
| 0.56 | 8.96 | 14.00 | - | 4.48 |
| 0.63 | 10.08 | 15.75 | - | 5.04 |
| 0.75 | 12.00 | 18.75 | - | 6.00 |
| 0.88 | 14.08 | 22.00 | - | 7.04 |
| 1.00 | 16.00 | 25.00 | 36.00 | 8.00 |
| .1.13 | 18.08 | 28.25 | 40.00 | 9.04 |
| 1.25 | 20.00 | 31.25 | 45.00 | 10.00 |
| 1.38 | 22.03 | 34.50 | 50.00 | 72.00 |
| 1.50 | 24.00 | 37.50 | 54.00 | 12.00 |
| 1.75 | 28.00 | 43.75 | 63.00 | 14.00 |
| 2.00 | 32.00 | 50.00 | 72.00 | 16.00 |
| 2.25 | 36.00 | 56.25 | 81.00 | 18.00 |
| 2.50 | 40.00 | 62.50 | 90.00 | 20.00 |
| 2.75 | 44.00 | 68.75 | 99.00 | 22.00 |
| 3.00 | 48.00 | 75.00 | 108.00 | 24.00 |
| 3.25 | 52.00 | 81.25 | 117.00 | 26.00 |
| 3.50 | 56.00 | 87.50 | 126.00 | 28.00 |
| 3.75 | 60.00 | 93.75 | 135.00 | 30.00 |
| 4.00 | 64.00 | 100.00 | 144.00 | 32.00 |
| 4.25 | 68.00 | 106.25 | 153.00 | 34.00 |
| 4.50 | 72.00 | 112.50 | 162.00 | 36.00 |
| 5.00 | 80.00 | 125.00 | 180.00 | 40.00 |
| 5.50 | 88.00 | 137.50 | 198.00 | 44.00 |
| 6.00 | 96.00 | 150.00 | 216.00 | 48.00 |
| 6.50 | 104.00 | 162.50 | 234.00 | 52.00 |
| 7.00 | 112.00 | 175.00 | 252.00 | 56.00 |
| 7.50 | 120.00 | 187.50 | 270.00 | 60.00 |
| 8.00 | 128.00 | 200.00 | 288.00 | 64.00 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|
| Alloy Steel Gr 12 | 0.05 – 0.17 | 0.40-0.65 | 0.15 – 0.40 | 0.035 max | 0.035 max | 0.80 – 1.15 | 0.45 – 0.60 | – | – |
| Grade | Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
|---|---|---|---|---|---|
| ASTM A387 Gr. 12 Cl. 1/2 | 380 – 550 | 230 min | 22% min | 18% min | – |
You May Also Like Buy These Grades :
- Chromium Molybdenum Gr 12 Strips
- Chrome Moly Grade 12 HR Sheets
- WERKSTOFF NR. 1.7335 Perforated Sheet
- Alloy Steel Grade 12 Foils
- Cr-Mo Grade 12 Sheets Manufacturer
- EN 13CrMo4-5 HR Sheets
- DIN 1.7335 Sheets Suppliers in India
- CrMo Grade 12 Sheet Mill Finish
- UNS K11757 Shim Sheets
- Alloy Steel Gr 12 Sheets Stockist in Mumbai
We Manufacturer, Supplier and Exporter ASTM SA387 Gr 12 Alloy Steel Sheets for wide range of industries. Some of the examples are : – Architectural applications, Refineries, Water Pipelines, Shipbuilding, Sugar Mills, Food & Beverages, Railways, Dairies & Breweries, Petrochemicals, Pharmaceuticals, Paper & Pulp Industries, Automobiles, Textiles, Chemicals, Constructions, Power Plants, Nuclear etc.
